JLT 1014P Rugged Vehicle Mounted Computer

The JLT1014P is the most compact rugged vehicle mounted computer available.  Powerful with great screen and multiple interfaces this is the ultimate where space is at a premium.

JLT Service Agreement

Reliable performer that fits anywhere

The JLT1014P gives you the main features of the JLT1214P – one of the most reliable workhorses for the logistics industry – but in the industry’s most compact form factor, making it the perfect choice for installation in tight spaces.

The JLT1014P is designed from the ground up for the challenges of logistics applications. It packs the latest technology for maximum reliability and trouble-free operation in tough environments. Combining true ruggedness with outstanding convenience, it’s ideal for forklifts or other logistics vehicles.

Featuring an Intel® Quad Core E3845 processor and an optional sunlight-readable XGA display, the JLT1014P computer is ready for anything. High-sensitivity PIFA antennas for Wi-Fi and Bluetooth ensure reliable wireless communication over long distances in challenging environments.

KEY FEATURES

  • Windows operating system
  • 10.4” standard or sunlight-readable display
  • Intel® Celeron E3845 quad core processor
  • IP65 waterproof and dustproof
  • Virtually unbreakable JLT PowerTouch™ display
  • Dual-diversity PIFA WLAN antennas
  • Smallest footprint on the market, ideal for use in tight spaces
  • Optional integrated mobile broadband modem
PHYSICAL
SIZE

251mm (w) x 218mm (h) x 46mm (d)

9.88 inch (w) x 8.58 inch (h) x 1.81 inch (d)



WEIGHT

2.2 kg / 4.0 LB

SYSTEM ARCHITECTURE
PROCESSOR

Intel® E3845



RAM

4GB DDR3



BOOT MEDIA

CFast 16GB, 32GB, 64GB, 128GB, 256GB



DISPLAY

10.4” XGA LED 400NIT

10.4” XGA LED 800NIT

Capacitive touch screen with JLT PowerTouch™ technology and hardened glass



OPERATING SYSTEM

Windows 10 IoT LTSC

Windows Embedded Standard 7

Windows 7

RF OPTIONS
BLUETOOTH

v4.2

WLAN

Dualband WLAN 802.11 ac, MU-MIMO supported



WWAN NORTH AMERICA

4G (LTE) up to 100 Mbps download speed (optional)



ANTENNAS

User configurable external or internal WLAN and Bluetooth antennas

WLAN dual diversity antennas (PIFA)

ENVIRONMENT
OPERATING TEMPERATURE

-30°C to 55°C / -22°F to 131°F



STORAGE TEMPERATURE

-35°C to 75°C / -31°F to 167°F

HUMIDITY

10–95% RH

DUST AND WATER

IP65 – IEC 60529:2001

VIBRATION

5–500 Hz/0,04 m/s2 XYZ – IEC 60068-2-64 Fh

SHOCK

30g for 11ms XYZ – IEC 60068-2-27

MIL-SPEC

810G in applicable areas

INTRFACES
AUDIO

HD audio

Waterproof stereo speakers



BUTTONS

LED dimming +/-

Power



PORTS

1x Ethernet 10/100/1000

1x RS232 with 5V

4x USB 2.0



INPUT

9-36 VDC unisolated
